电机型号 | 工作电压 | No load | At maximum efficiency | At stall | ||||||
转速 | 电流 | 转速 | 电流 | 力矩 | 功率 | 效率 | 电流 | 力矩 | ||
r/min | A | r/min | A | mNm | W | % | A | mNm | ||
RS-360SAV-22117B | 6VDC | 7200 | 0.20 | 5857 | 0.87 | 5.12 | 3.14 | 60.00 | 3.81 | 27.46 |
RS-360SA-10192 | 12VDC | 8500 | 0.13 | 6332 | 0.38 | 3.00 | 1.99 | 43.60 | 1.11 | 11.77 |
RS-365SAV-12175 | 24VDC | 11300 | 0.09 | 9136 | 0.38 | 5.54 | 5.30 | 58.30 | 1.60 | 28.93 |
RS-365SA-1875 | 12VDC | 12700 | 0.24 | 10110 | 0.98 | 6.10 | 6.50 | 55.50 | 3.81 | 30.11 |
