电机型号 | 工作电压 | No load | At maximum efficiency | At stall | ||||||
转速 | 电流 | 转速 | 电流 | 力矩 | 功率 | 效率 | 电流 | 力矩 | ||
r/min | A | r/min | A | mNm | W | % | A | mNm | ||
RS-370CHV-10750 | 12VDC | 2550 | 0.008 | 2160 | 0.05 | 1.65 | 0.37 | 69.10 | 0.25 | 10.79 |
RS-370CHV-11640 | 12VDC | 3050 | 0.012 | 2560 | 0.06 | 1.89 | 0.51 | 67.10 | 0.33 | 11.77 |
RS-370CHV-12510 | 12VDC | 3900 | 0.017 | 3289 | 0.09 | 2.12 | 0.73 | 66.90 | 0.49 | 13.53 |
RS-370CHV-081000 | 24VDC | 3900 | 0.008 | 3294 | 0.04 | 2.01 | 0.69 | 65.60 | 0.24 | 12.95 |
