电机型号 | 工作电压 | No load | At maximum efficiency | At stall | ||||||
转速 | 电流 | 转速 | 电流 | 力矩 | 功率 | 效率 | 电流 | 力矩 | ||
r/min | A | r/min | A | mNm | W | % | A | mNm | ||
FK-260SA-16190 | 3VDC | 2800 | 0.08 | 2116 | 0.26 | 1.70 | 0.37 | 47.60 | 0.80 | 6.87 |
FK-260SA-14124 | 3VDC | 5000 | 0.15 | 3653 | 0.41 | 1.30 | 0.51 | 41.90 | 1.10 | 4.90 |
FK-260SA-11380 | 12VDC | 6400 | 0.04 | 5168 | 0.17 | 2.20 | 1.17 | 57.70 | 0.71 | 11.28 |
FK-260SAV-18120 | 6VDC | 10400 | 0.15 | 8484 | 0.66 | 2.70 | 2.39 | 60.00 | 2.94 | 14.61 |
